The CageKits NA / NB Miata Formula Drift / Road Race Spec Roll Cage Kit is engineered for maximum strength, precision, and compliance with FD, NASA, or SCCA standards depending on the weight of the gutted chassis. Built from 1.5″ x .095″ 1020-1026 DOM tubing. Designed specifically for the MX-5 NA (1990-1997) and NB Miata (1999-2005), each tube is CNC-notched, precision-bent, and laser-etched for exact placement—ensuring a clean, straightforward installation with no custom fabrication required.
Made to Order — Ships Upon Completion
Door Bar Style and Depth
This kit includes X style door bars.
-
Gutted Door Bar Depth – Sits deep within the door cavity for maximum side clearance. Full removal of OEM door cards is required. Windows will not remain.
Technical Details
This cage was developed using a chassis with the OEM soft top installed. Included roof brackets are designed to match the factory soft top mounting points.
- Built from 1.5″ DOM tubing
- CNC-notched joints for precise, tight fitment
- Laser-etched placement guides for easy tube identification
- Precision-bent to match MX-5 Miata chassis geometry
- NASA / SCCA–inspired design and layout
- Supersedes Drift Spec structures in tube sizing and layout requirements
- Includes roof brackets that match the mounting location of the OEM soft-top
Installation & Compliance Notes
-
Compliance Responsibility: Customers are responsible for verifying that this roll cage meets the rules and technical requirements of their racing organization or sanctioning body.
-
Cages are optimized for competition and off-street applications.
Want to see it in action? Check out our Instagram.
Need install help? Media tab’s got you.
