SKU: GR-A-1001
FIA Spec – Made to Order – Ships When Complete
Overview
The Subaru GR FIA Spec Roll Cage Kit is engineered for competitive motorsports, meeting FIA Article 253 and Rally (ARA) safety standards. Purpose-built for the 2008–2014 Subaru WRX and STI hatchback (GR chassis), this cage offers uncompromising structural protection using 1.75″ x .095″ DOM steel tubing throughout the primary framework.
This is a precision-engineered, weld-in kit. Every component is CNC-notched and mandrel-bent for seamless installation, and laser-etched fitment guides make setup intuitive. Please verify rulebook compliance with your sanctioning body before ordering.
Key Features
Vehicle Fitment: Subaru WRX / STI Hatchback (2008–2014, GR chassis)
Material:
-
Main Structure: 1.75″ x .095″ DOM steel tubing
FIA Spec Compliance:
-
Built to FIA Article 253 rally specifications
-
Compliant with Rally (ARA) tech requirements
Weld-In Design: Requires professional welding and chassis prep
CNC Notched & Mandrel Bent Tubing for optimal fit and assembly
Laser-Etched Fitment Guides for precise, repeatable placement
Comprehensive Structure Includes:
-
Main Hoop, Front Top Bar, Rear Down Bars, and A-Pillars
-
Door Bars, Tube Gussets, FIA Bars, Dash Bar, Harness Bar
FIA Door Bar Options:
-
Reinforced with Taco Gussets for improved side impact protection
-
Compatible with OEM interior (trimming required)
-
Designed to retain window function
Additional Reinforcements:
-
Tube Gussets for joint strength
-
Dash Bar for frontal integrity and chassis triangulation
-
Harness Bar and FIA Bars for added safety and harness alignment
Description
The Subaru GR FIA Spec Roll Cage Kit delivers high-performance protection for drivers in rally, time attack, or drift disciplines. Constructed from 1.75″ x .095″ DOM tubing, the main structure offers maximum rigidity while maintaining weight-conscious design principles. Each tube is pre-cut, mandrel bent, and laser-etched to ensure a perfect weld-in fit for the GR chassis.
Developed to meet FIA Article 253 and Rally (ARA) standards, this kit is ideal for builders who need true motorsport safety in a hatchback platform. The layout allows for functional windows and OEM trim retention with minimal trimming—making it a smart option for dual-purpose or full-competition builds.
This is a weld-in only roll cage. Professional installation and precise fitting are required. Confirm compliance with your specific sanctioning body before purchase.
Important Notes
-
Made to order – All sales are final
-
Door bar design supports OEM interior and window function
-
Meets FIA Article 253 and Rally (ARA) regulations
-
Requires professional welding and proper vehicle prep
-
Confirm rulebook compliance before purchase
Want to see it in action? Check out our Instagram.
Need install help? Media tab’s got you.
